Video/Audio Input
Two-way audio input:1-ch, RCA (2.0 Vp-p, 1kΩ)
IP video input:16-ch
IP Video input:Up to 8 MP resolution
Network
Incoming bandwidth:160Mbps
Outgoing bandwidth:80Mbps
Video/Audio Output
HDMI Output:1-ch, resolution:4K (3840 × 2160)/30Hz,1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 ×1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz.
Recording Resolution:8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Audio Output:1-ch, BNC (Linear, 600Ω)
Synchronous Playback:16-ch
VGA Output:1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz
Decoding
Live view / Playback:8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Capability:1-ch @ 8 MP / 4-ch @ 1080p
Hard Disk
SATA:2 SATA interfaces
Capacity:Up to 6TB capacity for each HDD
External Interface
Network Interface:1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface
USB Interface:2, USB2.0
POE
Supported Standard:AF and AT
Interface:24 independent 10/100 Mbps PoE Ethernet interfaces
General
Power Supply:100 to 240 VAC
Consumption(without hard disk and POE):≤ 15W
Working Temperature:-10 oC ~ +55 oC (+14 oF~ + 131 oF)
Working Humidity:10 % ~ 90 %
Chassis:1U chassis
Dimensions:385 × 315 × 52 mm (15.2″× 12.4″ × 2.0″)
Weight(without HDD):≤ 2.6 kg (5.7 lb)
