Camera
Image Sensor: 4 MP CMOS image sensor
Signal System: PAL/NTSC
Effective Pixels: 2560 (H) × 1440 (V)
Min. Illumination: 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time: 1/25(1/30) s to 1/50,000 s
Lens: 2.8 mm to 12 mm
Lens Mount: φ14
Adjustment Range: Pan: 0° to 355°, Tilt: 0° to 75°, Rotation: 0° to 355°
Day& Night: IR cut filter
Video Frame Rate: PAL: 1080p@25fps, 4 MP@25fps
NTSC: 1080p@30fps, 4 MP@30fps
HD Video Output: 1 Analog HD output
Synchronization: Internal Synchronization
BLC: Support
Menu
D/N Mode: Auto / Color / B/W
BLC: Support
AGC: High/Medium/Low/Off
Function: Brightness, Sharpness, DNR, Mirror, Smart IR
Interface
Video Out: 1 HD analog output
General
IR Range: Up to 40 m
Operation Condition: -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
Power Supply: 12 VDC±15%
Power Consumption: Max. 4.4 W
Impact Protection: IK10.
Weather Proof: IP66
Dimension: 130 mm × 143 mm (5.11″ × 5.62″)
Weight: 630 g (1.39 lb.)
